Figure 3-3 The left side of the computer (P70-A)
Figure 3-4 The left side of the computer (X70-A)
1. Security lock slot 4. Universal Serial Bus (USB 3.0) port
2. TV tuner jack* 5. Universal Serial Bus (USB 3.0) port
3. LAN jack 6. Optical disc drive
* Provided with some models.
Product appearance depends on the model you purchased.
Security lock slot A security cable can be attached to this slot and
then connected to a desk or other large object in
order to deter theft of the computer.
TV Tuner jack Connect the coaxial cable to this port to watch
TV programs on your computer or record them.
The dimensions and shape of the TV Tuner jack
vary for different regions. Some models are
equipped with a TV tuner.
LAN jack This jack lets you connect to a LAN. The adaptor
has built-in support for Ethernet LAN (10
megabits per second, 10BASE-T), Fast Ethernet
LAN (100 megabits per second, 100BASE-TX) or
Gigabit Ethernet LAN (1000 megabits per
second, 1000BASE-T). Refer to Operating
Basics, for details.
Do not connect any cable other than a LAN cable to the LAN jack. It could
cause damage or malfunction.
User's Manual 3-3
