FILE NO. SVM-06037
− 8 −
2-3. Outdoor Unit (RAS-07GAH-E, RAS-07GA-E, RAS-07GAX)
Z
Cover PV
54
273.5
59.5
∅ 420
500
97.5
(11)
297
(12.5)273.5 (pitch)
660
242
56
A Detail Drawing (Back Leg)
660
50
36
R 15
R 5.5
273.5
265
∅ 6 Hole
B Detail Drawing (Front Leg)
50
36
R 15
660
265
273.5
∅ 6 Hole
∅
11x14 Hole
A
B
Z
View
97
∅
25Drain outlet
2-
∅ 11x14 hole
(for
∅ 8- ∅ 10 anchor bolt)
Fan guard
530
Liquid side
(Flare
∅ 6.35)
Gas side
(Flare
∅ 9.62)
Service port
126
48
237.5
45 or more
100 or more
400 or more
600 or more
Installation dimension
500
Air inlet
Air outlet
4x
∅ 11x14 Long holes (for ∅ 8- ∅ 10 anchor bolt)
