Installation Manual
‒ 33 ‒
33-EN
Adjustment of air direction
1. Using the remote controller switch, change the
up/down air direction by moving the horizontal
louver.
2. Adjust the right/left air direction by bending the
vertical grille inside of the air outlet port with
hands.
REQUIREMENT
Do not touch the horizontal louver directly with
hands; otherwise a trouble may be caused.
For handling of the horizontal louver, refer to
“Owner’s Manual” attached to the outdoor unit.
4
Push button to return to the normal
display.
Indoor unit data
CODE
No.
Data name
01 Room temperature (remote controller)
02 Indoor unit intake air temperature (TA)
03
Indoor unit heat exchanger (coil) temperature
(TCJ)
04
Indoor unit heat exchanger (coil) temperature
(TC)
F3
Indoor unit fan cumulative operating hours
(x1h)
Outdoor unit data
CODE
No.
Data name
60
Outdoor unit heat exchanger (coil)
temperature (TE)
61 Outside air temperature (TO)
62 Compressor discharge temperature (TD)
63 Compressor suction temperature (TS)
64 —
65 Heatsink temperature (THS)
6A Operating current (x1/10)
F1
Compressor cumulative operating hours
(x100h)
To Next Page
