Figure 3-1 Front of the computer with display panel closed (CL10-C/L10-C)
1. DC IN/Battery indicator 3. Wireless communication indicator
2. Power indicator
Product appearance depends on the model you purchased.
DC IN/Battery
indicator
The DC IN/Battery indicator shows the condition
of the DC IN and the battery charge status. White
indicates the battery is fully charged while the
power is being correctly supplied from the AC
power adaptor.
Refer to the Power Condition Descriptions
section for more information on this feature.
Power indicator The Power indicator glows white when the
computer is turned on. However, if you turn off
the computer into Sleep Mode, this indicator
blinks white.
Wireless
communication
indicator
The Wireless communication indicator glows
amber when the Bluetooth or Wireless LAN
functions are turned on.
Only some models are equipped with Bluetooth
and Wireless LAN functions.
Left side (CL10-C/L10-C)
The following figure shows the left side of the computer.
User's Manual
3-2
