Underside (CL10W-C/L10W-C)
The following figures show the underside of the computer. Ensure that the
display is closed before the computer is turned over to avoid causing any
damage.
Figure 3-12 The underside of the computer (CL10W-C/L10W-C)
1. Stereo speakers 2. Force Shut down hole
Stereo speakers The speakers emit sound generated by your
software as well as audio alarms, such as low
battery condition, generated by the system.
Force Shut down hole Insert a slender object such as a needle into this
hole to force a shut down when the computer is
hung.
Front with the display open (CL10W-C/L10W-C)
This section shows the computer with the display panel open. In order to
open the display, lift up the display panel and position it at a comfortable
viewing angle for you.
User's Manual
3-12
