7. How to set the environment for OPC Server
84
Reading and writing action mode of TC-net items and OPC items in a simulation mode in the following.
The item that a Mode column is gray shows that an action is different from a normal mode.
Table 7.1 List of OPC items (simulation mode)
Prefix
Item Name
Description
Data Type
Mode
Item Name and Data Type are imported from nV Tool.
R/W
Tcnet ScanMode Scan running state / Start or Stop control VT_UI4 R/W
ScanHealthyMap.Block#nnnn
Scan healty map [#0000 - #2047 / #4095]
VT_BOOL
R/W
ClearScanUnHealthyMap Clear scan healthy map VT_UI4 R/W
ScanSendCycle.HScanCyc
High scan transmission cycle
VT_UI2
RO
ScanSendCycle.MScanCyc
Middle scan transmission cycle
VT_UI2
RO
ScanSendCycle.LScanCyc
Low scan transmission cycle
VT_UI2
RO
ScanSendCycle.MaxNodeDist Maximum distance between nodes VT_UI2 RO
ScanSendCycle.MaxRepeater
Maximum repeater steps
VT_UI2
RO
ScanSendCycle.LoopTotalExt System total length (loop total length), Unit : 1km VT_UI2 RO
ScanSendCycle.MaxUtghJtgiDist
Star maximum length, Unit : 0.1km
VT_UI2
RO
ScanTalkerBlock.HScan.Block#nnn
Scan talker block (High speed) [#000 - #064 / #128]
VT_UI2
RO
ScanTalkerBlock.MScan.Block#nnn
Scan talker block (Middle speed) [#000 - #128 / #256]
VT_UI2
RO
ScanTalkerBlock.LScan.Block#nnn Scan talker block (Low speed) [#000 - #384 / #640] VT_UI2 RO
ScanTalkerMap.Block#nnnn
Scan talker map [#0000 - #2047 / #4095]
VT_UI2
R/W
ClearScanTalkerMap Clear duplicate blocks of scan talker block map VT_UI4 R/W
InringMap.Mac#nnn
Inling map [#000 - #255]
VT_BOOL
R/W
StationInf.RegInf
Station information (Error counter)
VT_UI4
R/W
StationInf.Mac#nnn.MacInf#d
Station information [Mac:#000 -#255, Diag:#0 -#3]
VT_UI2
R/W
ClearStationInf Clear station information VT_UI4 R/W
DualInf#d
Network dual diagnosis counter [[#0, #3 - #6]
VT_UI4
R/W
DualInf#1 Network dual diagnosis counter (A Bus Normal Count) VT_UI4 R(Sim)/W
DualInf#2
Network dual diagnosis counter (B Bus Normal Count)
VT_UI4
R(Sim)/W
ClearDualInf
Clear network dual diagnosis counter
VT_UI4
R/W
LinkControl
Link Control
VT_UI4
R/W
Version#d Version information [#0 - #2] VT_UI4
R/W
Correspondence#d
The correspondence acquisition of the rotary switch set value
and the card logic number [#0 - #1 / #2]
VT_UI2
R/W
SwitchConfig
Dipswitch value
VT_UI4
RO
HealthyCounter JTNI/JTGI healthy counter VT_UI2 R(Sim)/W
RasInfo.Mac#mmm.ContFlag
Station(#mmm) controller mounting information [Mac : #000 -
#255]
- Bit 15-8 : Module type
- Bit 7-0 : Controller mounting presence flag
VT_UI2 R/W
RasInfo.Mac#mmm.HealthyCounter
Station(#mmm) healty counter
VT_UI2
R(Sim)/W
RasInfo.Mac#mmm.Alarm
Station(#mmm) representation alarm
VT_UI2
R/W
RasInfo.Mac#mmm.Slot#d.HealthyCounter
Station(#mmm) slot(#d) healty counter [Slot: #0 - #7]
VT_UI2
R(Sim)/W
RasInfo.Mac#mmm.Slot#d.ContType
Station(#mmm) slot(#d) controller type
VT_UI2
R/W
RasInfo.Mac#mmm.Slot#d.ContSubType
Station(#mmm) slot(#d) controller type sub type
VT_UI2
R/W
RasInfo.Mac#mmm.Slot#d.PhaseMode
Station(#mmm) slot(#d) phase/mode
VT_UI2
R/W
RasInfo.Mac#mmm.Slot#d.Alarm
Station(#mmm) slot(#d) representation alarm
VT_UI2
R/W
