Toshiba TCB-IFTH1GUL User Manual

24V Thermostat Interface
Installation Manual
9-EN
 Wiring Example
Two-stage Cooling and Heating
Single-stage Cooling and Heating with dedicated three Fan-Speed
Remote Controller (Optional)
A
B
Transformer
24VAC
Indoor Unit
A
B
Transformer:
Field procured
Thermostat
72
24VAC
Fan
Remote Controller (Optional)
A
B
Transformer
24VAC
Indoor Unit
A
B
Transformer:
Field procured
Thermostat
72
24VAC
Fan
24V Thermostat
Interface
TCB-IFTH1GUL
24V Thermostat
Interface
TCB-IFTH1GUL
Installation use only
Set the Remote Controller
as “Follower remote control”.
Installation use only
Set the Remote Controller
as “Follower remote control”.
For use only on
24 volt circuits
For use only on
24 volt circuits
