Toshiba Tecra Z50-C Series User Manual

Figure 2-2 Connecting the power cord to the AC adaptor (3-pin plug)
Either a 2-pin or 3-pin adaptor/cord is included with the computer
depending on the model.
2. Connect the DC output plug of the AC adaptor to the DC IN 19V jack
on your computer.
Figure 2-3 Connecting the DC output plug to the computer
1
2
1. DC IN 19V jack 2. DC output plug
Product appearance depends on the model you purchased.
3. Plug the power cord into a live wall outlet. The DC IN/Battery indicator
glows.
Opening the display
The display panel can be opened to a wide range of angles for optimal
viewing.
While holding down the palm rest with one hand so that the main body of
the computer is not raised, slowly lift the display panel. This will allow the
angle of the display panel to be adjusted to provide optimum clarity.
Figure 2-4 Opening the display panel
1
1. Display panel
User's Manual 2-4

Toshiba Tecra Z50-C Series Specifications

General

Storage	SSD or HDD options, varies by configuration
Graphics	Intel HD Graphics 520
Operating System	Windows 10 Pro
Ports	USB 3.0, HDMI, VGA, Ethernet, SD card reader, headphone/microphone combo jack
Wireless	Wi-Fi 802.11ac, Bluetooth 4.0
Optical Drive	DVD SuperMulti drive
Webcam	HD webcam with microphone
