E6581136
10
<VFA7 - 11 to 22kW, VFP7 - 18.5/22kW >
Connector (CN21)
LED for R0 and S0
R0, S0
terminal board
Keyhole for wiring
Wiring
2-M3 screws
Recommended
tightening torque
0.5Nm(4.4lbs-in)
