E6581136
9
<VFA7 - 5.5 / 7.5kW>
R0, S0
terminal board
Connector (CN21)
LED for R0 and S0
Keyhole for wiring
Wiring
2-M3 screws
Recommended
tightening torque
0.5Nm(4.4lbs-in)
