E6581136
8
Connection explanatory drawing
<VFA7 - 0.4 to 3.7kW>
Connector (CN21)
LED for R0 and S0
R0, S0
terminal board
Keyhole for wiring
Wiring
Wiring inlet plate
2-M4 screws
Recommended
tightening torque
1.2N･m(11lbs-in)
