Toshiba TOSVERT VF-P7

E6581136
7
Circuit explanatory drawing
<Standard>
R0-S0
POWER
R0-S0
POWER
<< Inverter main unit>>: 22kW or less
《 Control power option 》
R/L1
S/L2
T/L3
R0
S0
R0
S0
<When control power option is installed>
CN21
CN21
<Note> R0 and S0 are normally
not connected to the
control power circuit.
Control power
<<Inverter main unit>>: 22kW or less
Main circuit power
Jumper
connector
DC/DC
Control power
circuit
DC/DC
Control power
circuit
