Toshiba TOSVERT VF-P7 User Manual

E6581172①
11
4.3. Light-load detection mode
When F342 (Light-load detection mode) is used, the sign of the positive and negative can be judged for F335~F340.
F342 is set as follows.
1) Set “+128" for the detection with the sign.
2) Set “+0" when it is rolling up of the forward rotation. When it is small compared with the detection
level, it is judged a light load.
Set “+64" when it is rolling up of the reverse rotation. When it is large compared with the detection
level, it is judged a light load.
3) Judge the positive and negative of each mode according to the table below, and total the value.
4) Set the total of 1)~3) to F342.
Ex.) Forward: roll up, reverse: roll down, d
etection with torque
1)The torque of the table below is detected by the light load.
2)Setup value of F335~F340 and F342 becomes a table below.
3)Set the following parameters.
F342
Title Function
Positive Negative
F335
Switching load torque current during
forward run
+0 +1
F336
Heavy load torque during
acceleration in forward direction
+0 +2
F337
Heavy load torque during fixed
speed in forward direction
+0 +4
F338
Switching load torque current during
reverse run
+0 +8
F339
Heavy load torque during
acceleration in reverse direction
+0 +16
F340
Heavy load torque during fixed
speed in reverse direction
+0 +32
Torque monitor
Operation mode
Forward(roll up） reverse(roll down）
During fixed speed in light load
judgment frequency
+30% -10%
During acceleration
+90% -70%
During fixed speed of high-speed
operation
+40% -20%
Title Function
Setup value *1 F342
F335
Switching load torque current
during forward run
35% +0(Positive)
F336
Heavy load torque during
acceleration in forward direction
95% +0(Positive)
F337
Heavy load torque during fixed
speed in forward direction
45% +0(Positive)
F338
Switching load torque current
during reverse run
15% +8(Negative)
F339
Heavy load torque during
acceleration in reverse direction
75% +16(Negative)
F340
Heavy load torque during fixed
speed in reverse direction
25% +32(Negative)
*1 Margin of 5%
Title Function
Setup value
F330
Light-load high-speed operation
6〜10 (torque)
F335
Switching load torque current
during forward run
35
F336
Heavy load torque during
acceleration in forward direction
95
F337
Heavy load torque during fixed
speed in forward direction
45
F338
Switching load torque current
during reverse run
15
F339
Heavy load torque during
acceleration in reverse direction
75
F340
Heavy load torque during fixed
speed in reverse direction
25
F342
Light-load detection mode
184 (128+8+16+32)
