Toshiba TOSVERT VF-S15 series Instruction Manual Supplementary

E6582185
11
Control circuit terminals
The control circuit terminal block is common to all equipment.
Terminal
symbol
Input /
output
Function
Electrical
specifications
Note 4)
FLA
FLB
FLC
Note 3)
Output
Multifunction programmable relay contact output.
Detects the operation of the inverter's protection
function.
Contact across FLA-FLC is closed and FLB-FLC is
opened during protection function operation.
Max. switching capacity
250Vac (OVC II) -2A,
30Vdc-2A
(cosφ=1)
: at resistive load
250Vac (OVC II) -1A
(cosφ=0.4)
30Vdc-1A
(L/R=7ms)
Min. permissible load
5Vdc-100mA
24Vdc-5mA
RY
RC
Note 3)
Output
Multifunction programmable relay contact output.
Default settings detect and output low-speed signal
output frequencies.
Multifunction output terminals to which two different
functions can be assigned.
Note 3) A chattering (momentary ON/OFF of contact) is generated by external factors of the vibration and
the impact, etc. In particular, please set the filter of 10ms or more, or timer for measures when connecting
it directly with input unit terminal of programmable controller. Please use the OUT terminal as much as
possible when the programmable controller is connected.
Note 4) OVC II: Overvoltage category II

Toshiba TOSVERT VF-S15 series Specifications

General

Series	VF-S15
Category	Inverter
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication Options	Modbus
Braking Unit	Built-in
Power Rating	0.4 kW to 15 kW
Input Voltage	Single-phase 200 to 240V, Three-phase 200 to 240V, 380 to 480V
Cooling Method	Fan cooling
