43
TFT Color Sc reen 5"
Power DC 9~15V
Battery 3S 18650 (Optional)
Built-in Lithium Charger Yes
AC-DC power supply Optional
Water Proof Splashproof
Max. Depth 40m
Sonar coverage 60 degree
Ping Rate 6Hz
Sonar Software Engine Gen3
Hardware Gain Adjustable Yes
User Defined Color Scheme Support Yes
Color Route to Indicate Depth(2D Map) Yes
tsl2 logger for SonarViewer N/A
Radio Frequency 2.4GHz
Radio Power(Max) 20dBm
Frequency-hopping spread spectrum (FHSS) Yes
Direct-sequence spread spectrum (DSSS) Yes
Max Range 300m
GPS Accuracy(CEP) 2.5m
Compass at Boat Side Yes
Compass at Dispaly Side Yes
Waypoint Number 500
Routes to be Saved 10
Two propellers boat support Yes
propeller & Rudder boat support Yes
Steering Sensitivity Adjustable Yes
Wiring Test Mode Yes
Push-Go Key(shortcut) Yes
Pick up waypoint form map Yes
Google kml import to Define Lake Boundary Yes
Sonar unit size
170*110*46mm
Portable case size 262 x 150 x 98mm
GPS receiver cable length 0.7m
Transducer cable length
0.6m
Operational temperature
-10°C ~ 50°C
Autopilot
Technical
and casing
BASIC
Echo Sounder
Radio System
GPS & Compass
Specifications
