Installing Your AC
Here are the detailed instructions for installing the window panel into sliding sash
or hung windows. For certain windows, such as a casement window, you will need
to improvise several steps of the installation as each specific window will be different.
1. Cut the Foam seal B (adhesive type) to the proper length and attach it to your
horizontal (or vertical) sliding window.
Foam seal B
(adhesive type)
Foam seal B
(adhesive type)
2. Attach the insect guard to the back side of the window panel. Push in to ensure
that it fits securely. If you do not want to install the rain guard, skip to Step 4 below.
3. Optional: Install the rain guard over the insect guard to prevent rainwater from
leaking into the exhaust hose.
a. Insert the three projections on each rain guard into the holes in the insect guard.
Side “A” should be at the top, as indicated in the diagram below.
