Parts name
Indoor Unit
air outlet
■
If remote controller is lost or damaged, please use aux. button to turn on or turn off the air
conditioner. The operation in details is as below: As shown in the figure, open panel and
press aux.button to turn off the air conditioner. When the air conditioner is turned on, it will
operate under auto mode.
Display
Temp. indicator
Power indicator
This is the general introduction and the color of indicator is only for reference. Please refer to the actual
display.
Display content may be different from the actual. Please refer to the actual display.
5
air inlet
filter
panel
Notice
●
●
upper air guide louver
lower air guide louver
aux. button
panel
