126
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW12HQ1C8D/O
Product Code CB427W05900_L59684
1 Front Grill 01473012 1
2 Front Panel Assy 0000030001504 1
3 Axial Flow Fan 10333004 1
4 Chassis Sub-assy 017000000126P 1
5 Clapboard Sub-Assy 0123338502 1
6 Drainage Connecter / 0
7 Compressor Gasket 76710287 3
8 4-Way Valve Assy 030152000094 1
9 Valve Support 0171314201P 1
10 Cut off Valve 071302391 1
11 Cut off Valve 07133082 1
12 Valve Support Block 26113017 2
13 Right Side Plate Assy 013030713 1
14 Big Handle / 0
15 Magnet Coil 4300040050 1
16 Electric Expand Valve Fitting / 0
17 Rear Grill 01473009 1
18 Electric Box Sub-Assy 10000500540 1
19 Filter Board / 0
20 Main Board 30138001268 1
21 Reactor 43130184 1
22 Electric Box Assy 10000100885 1
23 Terminal Board 422000060016 1
24 Wire Clamp 71010003 2
25 Top Cover Sub-Assy 01253073 1
26 Condenser Assy 011002000134 1
27 Motor Support 0170310401 1
28 Fan Motor 1501306723 1
29 Compressor Overload Protector(External) / 0
30 Compressor and Fittings 00103364 1
31 Small Handle 26233100 1
32 Temperature Sensor 3900030805
1
To Next Page
