130
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Qty
TW24HQ1C8D/O
Product Code CB427W02400_L59684
1 Rear Grill 01473043 1
2 Front Panel Assy 0000030002401 1
3 Axial Flow Fan 10335008 1
4 Fan Motor 1501506402 1
5 Chassis Sub-assy 0280336702P 1
6 Drainage Connecter / 0
7 Gas-liquid Separator 07223048 1
8 Compressor and Fittings 00105249G 1
9 4-Way Valve Assy 03073324 1
10 Electric Expansion Valve Sub-Assy / 0
11 Valve Support Sub-Assy 01713098P 1
12 Cut off Valve 07130239 1
13 Valve Cover 22245002 1
14 Retaining Plate 02115006P 1
15 Handle Assy 02113109 1
16 Right Side Plate Assy 0130329202 1
17 Cut off Valve 07133157 1
18 Magnet Coil 4300040045 1
19 Clapboard Assy 0123315301 1
20 Condenser Assy 01100200347 1
21 Front Grill 01473049 1
22 Wiring Clamp 26115004 1
23 Coping Sub-Assy 000051000017 1
24 Motor Support Sub-Assy 0170512001 1
25 Drainage Plug / 0
26 Condenser Support Plate 01173415 1
27 Left Side Plate 01305093P 1
28 Left Handle / 0
29 Electric Box Assy 10000100294 1
30 Main Board 30138000673 1
31 Radiator 49010252 1
32 Electric Box 20113027 1
33 Wire Clamp 71010003 1
34 Wire Clamp 71010003 1
35 Terminal Board 42010255 1
36 Temperature Sensor 3900030901 1
37 Temperature Sensor / 0
38 Insulated Board (Cover of Electric Box) 20113003 1
To Next Page
