136
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW09CQ2B8DO
Product Code CB419W04200_L91250
1 Front Grill 01473012 1
2 Front Panel Assy 0153304901 1
3 Axial Flow Fan 10333004 1
4 Fan Motor 1501308507 1
5 Chassis Sub-assy 017000000181P 1
6 Compressor Gasket 76713027 3
7 Compressor and Fittings 00103892 1
8 Electric Expansion Valve Sub-Assy 07133769 1
9 Valve 07100003 1
10 Valve 07100005 1
11 Valve Support 01713041 1
12 Cable Cross Plate 1 02123013P 1
13 Right Side Plate 0130306903 1
14 Cover of Pass Wire 01413069 1
15 Electric Expand Valve Fitting 07200200001204 0
16 Discharge sensor / 0
17 Tube Sensor / 0
18 Discharge Tube 03813963 1
19 Inhalation Tube Sub-assy 03001000286 1
20 Compressor Overload Protector(External) 00183111 1
21 Temperature Sensor 3900030903 1
22 Rear Grill 01473057 1
23 Condenser Assy 01163412 1
24 Clapboard Sub-Assy 01233034 1
25 Top Cover Sub-Assy 00005106001201 1
26 Motor suport spot welding sub-assy / 0
27 Cover of Reactor Box 01413029 1
28 Reactor 43130185 1
29 Reactor Box 01413092 1
30 Electric Box Cover Sub-Assy 0260309601 1
31 Main Board 30138000522 1
32 Electric Box Assy 10000100187
1
33 Terminal Board 422000060016 1
To Next Page
