Tosot TW09HQ2C2D - Page 35

32
Technical Information
Service Manual
TW09HQ1B8A/I
TW12HQ1B8A/I
W
D
H
Unit:inch
Models WHD
09K 31 1/8 10 13/16 7 7/8
12K 33 1/4 11 3/88 1/4
12K
09K
3 9/16
5 7/8
2 1/8
6 5/818 1/46 1/4
Φ2 3/16
Φ2 3/16
2 1/8
4 7/821 5/16 7 1/16
3 1/4
4 15/16
1 3/8
Φ2 3/16
Φ2 3/16
1 3/8
TW09CQ2B8DI
Unit:inch
33 1/4
8 7/32
11 3/8
4 43/64
7 1/4
21 21/64
Φ2 3/16
Φ2 3/16
1 3/8
1 3/8
5
3 19/64
