30
1.
2.
Aim the pipe joint at the corresponding
bellmouth.
Pretighten the union nut with hand.
3.
2.
cut off
the hole
left right
When select leading out the pipe
from left or right, please cut off the
corresponding hole on the bottom
case.
1.
Adjust the torque force by referring to the following sheet. Place the open-end
wrench on the pipe joint and place the torque wrench on the union nut. Tighten
the union nut with torque wrench.
The pipe can be led out in the
direction of right, rear right, left or
rear left.
left
rear left
right
rear right
Step four: outlet pipe
Installation of indoor unit
pipe joint union nut
pipe
●
Note:
Pay attention to dust prevention and
take relevant safety measures when
opening the hole.
Indoor
5-10
outdoor
Φ55/
Φ70
To Next Page
