Technical Information
Service Manual
Model TW24HQ1C8D
Product Code CB456000200_L59684
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 22000
Heating Capacity(Min~Max) Btu/h 23000
Cooling Power Input(Min~Max) W 2260
Heating Power Input(Min~Max) W 2300
Cooling Power Current A 10.03
Heating Power Current A 10.20
Rated Input W 2750
Rated Current A 11.98
Air Flow Volume(SH/H/M/L) CFM 706/647/588/530
Dehumidifying Volume Pint/h 5.28
EER (Btu/h)/W 9.73
COP (Btu/h)/W 10.00
SEER 16.00
HSPF 9.00
Application Area yd
2
32.29-50.23
Indoor Unit
Model of indoor unit TW24HQ1C8D/I
Indoor Unit Product Code CB456N00200_L59684
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 1/4×32 7/10
Fan Motor Cooling Speed(SH/H/M/L) r/min 1250/1100/900/800
Fan Motor Heating Speed(SH/H/M/L) r/min 1150/1000/900/850
Output of Fan Motor W 30
Fan Motor RLA A 0.32
Fan Motor Capacitor μF 3
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch 0.286
Row-n Gap inch 2-1/17
Coil Length (LXDXW) inch 33 1/4×1×13 1/2
Swing Motor Model MP35CJ
Output of Swing Motor W 2.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 48/44/40/36/-
Sound Power Level(SH/H/M/L) dB (A) 58/54/50/46/-
Dimension (WXHXD) inch 42 7/16X12 13/16X9 11/16
Dimension of Carton Box (LXWXH) inch 45X16 1/8X13 3/16
Dimension of Package (LXWXH) inch 45 3/16X16 1/4X13 3/4
Net Weight Ib 37.5
Gross Weight Ib 45.2
