TW18HQ1C8D/O
Product Code CB427W02000_L59684
1 Front Grill 01473049 1
2 Front Panel Assy 0000030002401 1
3 Axial Flow Fan 10335008 1
4 Chassis Sub-assy 01700000093P 1
5 Drainage Connecter 06123401 1
6 Compressor and Fittings 00105249G 1
7 4-Way Valve Assy 030152000291 1
8 Valve Support Assy 01715010P 1
9 Cut off Valve 071302392 1
10 Cut off Valve 0713506803 1
11 Valve Cover 22245002 1
12 Handle 26233053 1
13 Right Side Plate Assy 0130329202 1
14 Magnet Coil 4300040045 1
15 Wiring Clamp 26115004 1
16 Temperature Sensor 3900030901 1
17 Rear Grill 01473043 1
18 Condenser Assy 01100200339 1
19 Clapboard Assy 01233153 1
20 Coping Sub-Assy 000051000017 1
21 Motor Support Sub-Assy 01703154 1
22 Fan Motor 1501506402 1
23 Condenser Support Plate 01173127 1
24 Left Side Plate 01305093P 1
25 Electric Box Assy 10000100288 1
26 Electric Box 20113027 1
27 Terminal Board 42010255 1
28 Radiator 49010252 1
29 Main Board 30138000685 1
