134
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW12HQ1B8A/O
Product Code CB427W03700_L59684
1 Front Grill 01473012 1
2 Front Panel Assy 0153304901 1
3 Axial Flow Fan 10333004 1
4 Fan Motor 1501308507 1
5 Chassis Sub-assy 0120388103P 1
6 Drainage Connecter 06123401 1
7 Compressor Gasket 76710302 3
8 Compressor and Fittings 00103862 1
9 Electric Expansion Valve Sub-Assy / 0
10 Valve Cover 2012300101 1
11 Cut off Valve 07130239 1
12 Valve 07100005 1
13 Valve Support 01713041 1
14 Cable Cross Plate 2 02123014P 1
15 Cable Cross Plate 1 02123013P 1
16 Right Side Plate Assy 013030713 1
17 Cover of Pass Wire 01413069 1
18 Electric Expand Valve Fitting / 0
19 Temperature Sensor 39000310 1
20 4-Way Valve Assy 03073403 1
21 Magnet Coil 4300040021 1
22 Compressor Overload Protector(External) 00180030 1
23 Rear Grill 01473057 1
24 Condenser Assy 01100200482 1
25 Clapboard Sub-Assy 01233034 1
26 Top Cover Sub-Assy 00005106001201 1
27 Motor Suport Spot Welding Sub-assy / 0
28 Electric Box Cover Sub-Assy 0260309601 1
29 Main Board 30138000863 1
30 Electric Box Assy 100002061850 1
31 Terminal Board 422000060016 1
To Next Page
