Technical Information
Service Manual
Model TW12HQ1B8A
Product Code CB438003902_L59684
Power Supply
Rated Voltage V~ 115
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 12000(3753~12500)
Heating Capacity(Min~Max) Btu/h 13000(3412~15013)
Cooling Power Input(Min~Max) W 1193(380~1300)
Heating Power Input(Min~Max) W 1250(350~1350)
Cooling Power Current A 12.40
Heating Power Current A 13.50
Rated Input W 1350
Rated Current A 13.20
Air Flow Volume(SH/H/M/L) CFM 400/318/241/194
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 10.06
COP (Btu/h)/W 10.40
SEER 16
HSPF 9
Application Area yd
2
19.14-28.70
Indoor Unit
Model of indoor unit TW12HQ1B8A/I
Indoor Unit Product Code CB438N03902_L59684
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 7/8X24 15/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1000/800
Fan Motor Heating Speed(SH/H/M/L) r/min 1350/1200/1000/900
Output of Fan Motor W 20
Fan Motor RLA A 0.25
Fan Motor Capacitor μF 4
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 25X7/8X12 1/16
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/39/35/29
Sound Power Level(SH/H/M/L) dB (A) 53/49/45/39
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X10 15/16X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11 1/16X14 15/16
Net Weight Ib 23.15
Gross Weight Ib 27.56
