16
Technical Information
Service Manual
Model TW09CQ2B8D
Product Code CB438000300_L91250
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 9000(3100~9600)
Heating Capacity(Min~Max) Btu/h /
Cooling Power Input(Min~Max) W 630(160~1300)
Heating Power Input(Min~Max) W /
Cooling Power Current A 2.80
Heating Power Current A /
Rated Input W 1300
Rated Current A 5.8
Air Flow Volume(SH/H/M/L) CFM 377/288/241/171
Dehumidifying Volume Pint/h 1.69
EER (Btu/h)/W 14.29
COP (Btu/h)/W /
SEER 23.00
HSPF /
Application Area yd
2
14.35-21.53
Indoor Unit
Model of indoor unit TW09CQ2B8DI
Indoor Unit Product Code CB438N00300_L91250
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 55/64X25
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750
Fan Motor Heating Speed(SH/H/M/L) r/min /
Output of Fan Motor W 20
Fan Motor RLA A 0.09
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ 2/7
Row-n Gap inch 2-1/18
Coil Length (LXDXW) inch 25X7/8X12 1/16
Swing Motor Model MP24BA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/39/35/29
Sound Power Level(SH/H/M/L) dB (A) 53/49/45/39
Dimension (WXHXD) inch 33 1/4X11 3/8X8 7/32
Dimension of Carton Box (LXWXH) inch 36 9/64X11X14 21/64
Dimension of Package (LXWXH) inch 36 1/4X11X15
Net Weight Ib 22.05
Gross Weight Ib 26.46
