Technical Information
Service Manual
Model GWC18AGDXF-D3DNA1A
GWH18AGDXF-D3DNA1A
GWH18AGDXF-D3DNA4A
Product Code CB385016900
CB385017000
CB558008900
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 18000 18000
Heating Capacity Btu/h / 18000
Cooling Power Input W 1384 1384
Heating Power Input W / 1384
Cooling Power Current A 6.7 6.3
Heating Power Current A / 6.3
Rated Input W 2300 2350
Rated Cooling Current A 11.5 11.5
Rated Heating Current A / 11.5
Air Flow Volume CFM 589/500/441/412/383/353/324 589/500/441/412/383/353/324
Dehumidifying Volume Pint/h 3.8 3.8
EER (Btu/h)/W 13 13
COP (Btu/h)/W / 13
SEER 23 23
HSPF / /
Application Area yd
2
28-41 28-41
Indoor
Unit
Model of indoor unit GWC18AGDXF-D3DNA1A/I
TW18HXP2A1DI
GWH18AGDXF-D3DNA4A/I
Indoor Unit Product Code CB385N16900
CB385N17000
CB558N08900
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф106×739 Ф106×739
Cooling Speed r/min 1400/1200/1120/1050/980/860/750 1400/1200/1120/1050/980/860/750
Heating Speed r/min / 1400/1200/1120/1050/950/850/750
Fan Motor Power Output W 45 45
Fan Motor RLA A 0.25 0.35
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7 Φ7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 745×22.8×342.9 745×25.4×342.9
Swing Motor Model MP24HF/MP24AK/MP24BA MP24HF/MP24AK/MP24BA
Swing Motor Power Output W 1.5/1.5/1.5 1.5/1.5/1.5
Fuse Current A 3.15A 3.15A
Sound Pressure Level dB (A) 48/43/41/40/38/34/31
Cooling: 49/43/41/40/37/33/29
Heating: 49/43/41/39/36/32/28
Sound Power Level dB (A) 58/53/51/50/48/44/41
Cooling: 49/43/51/50/47/43/39
Heating: 59/53/51/49/46/42/38
Dimension (WXHXD) inch 38 21/32 × 12 1/4 × 8 45/64 38 21/32 × 12 1/4 × 8 45/64
Dimension of Carton Box (LXWXH) inch 40 29/32 × 14 27/32 × 11 19/64 40 29/32 × 14 27/32 × 11 19/64
Dimension of Package (LXWXH) inch 41 7/64 × 15 5/32 × 11 11/16 41 7/64 × 15 5/32 × 11 11/16
Net Weight Ib 28.7 28.7
Gross Weight Ib 35.3 35.3
2. Specications
