TotalPond MF13010 - Connect Extension Tubes with Coupler; Attach Filter Box Top and Fountain Head; Place Filter Assembly in Water; Secure Filter Box

3
NOTE: From here, a coupler or a diverter valve can be used.
a. To flow water to the fountain head only, use the coupler. (Proceed to step 5)
b. To flow water to the fountain head and a spitter, use the diverter. (Skip to step 8)
5. Connect the two extension tubes with the coupler. Fig. 5
NOTE: Extension tubes and coupler are NOT INCLUDED.
Fig. 5
6. Place the filter box top over the filter box bottom and connect
the fountain head to the top extension tube. Fig. 6
NOTE: Fountain head kit is NOT INCLUDED.
Fig. 6
7. Place the filter assembly in the water. Fig. 7
Fig. 7
8. Place the filter box top on top of the filter box bottom. It
should snap closed. Fig. 8
Fig. 8
Extension
tube
Extension
tube
Coupler
Filter box
top
Fountain head
Filter box
top
Filter box
bottom
