TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and function
as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO
®
! ...........................................................................................3
Before Installation ...............................................................................................................3
Common Tools Needed ....................................................................................................3
Included Parts .....................................................................................................................3
Before Installation ...............................................................................................................4
Installation Procedure .....................................................................................................4-6
Toilet Tank Fill Valve Instructions ....................................................................................6-7
Care and Cleaning ..............................................................................................................7
Warranty ..............................................................................................................................8
Rough-In Dimensions ......................................................................................................21
Replacement Parts ............................................................................................................22
Check to make sure you have all these parts from the package:
COMMON TOOLS NEEDED
INCLUDED PARTS
• 10” adjustable wrench
• Hacksaw
• Carpenter’s Level
MATERIALS REQUIRED:
• Flexible Supply Tube / Connector
• Supply Stop Valve
• Tape Measure
• Pliers
• Screwdriver
• Putty Knife
Tank to Bowl Hardware:
China Bowl
China Tank
Bolts
(2 pieces)
China Tank Lid Tank to Bowl Gasket
Rubber Washers
(2 pieces)
Metal Washers
(4 pieces)
Nuts
(4 pieces)
Flange Caps (for the Bowl):
Plastic Caps
(2 pieces)
Base Caps
(2 pieces)
• Mounting (T) Bolts & Nuts (2pc)
• Wax Ring / Seal
To Next Page
