3. (1) allowing the unit to
slide to the bottom and remove the retainer tab by pulling as the arrow
indicates (3)
4.
5.
6. Remove the diaphragm from its housing by carefully pulling the edge
removing.
Use twisting motion while pulling to help with removal.
8. Rinse all parts under running water to clear any debris, residues or films.
Reinstall all parts in reverse order. Turn the water ON and check for leaks
and operation.
Ill. 1 Ill. 2 Ill. 3
Ill. 6
SERVICING THE FILL VALVE
Ill. 4
Ill. 5
-
1
2
Ill. 7
