Toto TLK01101 Series Installation Manual

2
部品名称
INCLUDED PARTS........................................................................................................ 3
安装步骤 INSTALLATION PROCEDURE ..................................................................................... 5
试运行 TESTING .........................................................................................................................13
TOTO致力于为世界提供更健康、卫生和舒适的生活方式。对于每一件产品，我们均以形式和功
能的平衡统一作为指导原则来设计。祝贺您作出了正确的选择。
The mission of TOTO is to provide the world with healthy, hygienic and more comfortable lifestyles.
We design every product with the balance of form and function as a guiding principle.
Congratulations on your choice.
目录 TABLE OF CONTENTS
感谢您选购TOTO！ THANK YOU FOR CHOOSING TOTO!
请阅读并遵守以下注意事项。否则可能导致人员伤亡或财产损失。
警告 WARNINGS
安装前 BEFORE INSTALLATION
 除非本手册中特别说明，除售后服务工程师以外的人员不得拆卸、修理或改造本皂液器。
否则可能会导致触电或产品故障。
 请勿在表面可能积聚冷凝水的潮湿环境（特别是桑拿房或蒸汽室）使用本皂液器。

请勿敲击或踢打吐皂口本体或机能部，否则可能会导致产品损坏或引起泄漏。
 请勿在室温低于冰点的房间使用本皂液器。
 请确保电源线不与热水供水管接触。
 请避免在红外感应器检测范围内放置任何物品。
 仅可使用TOTO指定的皂液才能避免保修失效。
 请确保电源插座位于使用期间不会受潮的位置。
Please read and adhere to the following notes. Failure to do so could result in personal injury
and/or property damage.
 No person other than a service engineer should disassemble, repair or modify this
dispenser, unless it is specifically described in this manual. Failure to do so may result in
electric shock or product malfunction.
 Do not use this dispenser in a humid location where condensation may collect on the
surface, especially in a sauna or steam room.

Do not strike or kick the dispenser or controller box, as this may damage the unit or cause a leak.
 Do not use this dispenser if the room temperature drops below freezing.
 Make sure the power cord does not come in contact with the hot water supply line.
 Avoid placing any objects within the detection range of the infrared sensor.
 Use only TOTO approved liquid soap to avoid invalidation of warranty.
 Make sure the electrical outlet is in a position where it will not get wet during use.
 为确保正确进行安装，请仔细阅读这些说明。
 TOTO保留更新产品设计的权利，恕不另行通知。
 请进行检查，确认您的产品中包含以下页面中显示的部件。
 Read these instructions carefully to ensure proper installation.
 TOTO reserves the right to update product design without notice.
 Check to make sure you have the parts indicated on the following page.
3
部品名称 INCLUDED PARTS
吐皂口本体
Controller
机能部
Spout parts
安装支架
Mounting bracket
沉头自攻螺丝
(Φ4x10)
Countersunk
tapping screw
(Φ 4 x 10)
螺丝
(Φ5 .1x 32)
Screw
(Φ 5.1 x 32)
固定板
Anchoring plate
(TLK03001G) (TLK02001G) (TLK02002G)

Toto TLK01101 Series Specifications

General

Brand	Toto
Model	TLK01101 Series
Category	Dispenser
Language	English
