TOUGHBUILT S510 - Part Lists; Tools Needed

1
2
3
4
5
6
7
8
9
10
Description
Stand & Rails
Universal Tool Mounts
Offset Mounting Bracket
21.1cm Solid Rubber Wheel
Axle Plate
Work Support
Work Stop
Pull Handle
M8x16 Carriage Bolt
M8x55 Carraige Bolt
Part Number
TB-S510-P-001
TB-S510-P-002
TB-S510-P-003
TB-S510-P-004
TB-S510-P-005
TB-S510-P-006
TB-S510-P-007
TB-S510-P-008
TB-S510-P-009
TB-S510-P-010
Qty.
1 pc
2 pcs
2 pcs
2 pcs
1 pcs
2 pcs
2 pcs
1 pc
2 pcs
4 pcs
11
12
13
14
15
16
17
18
19
Description
M8x25 Inside Hex Bolt
M8x16 Inside Hex Bolt
Φ8 Flat Washer
Φ8 Spring Washer
M8 Nut
M6X55 Carriage Bolt
M6 Knob Nut
M8x15 Knob
"C" clip
Part Number
TB-S510-P-011
TB-S510-P-012
TB-S510-P-013
TB-S510-P-014
TB-S510-P-015
TB-S510-P-016
TB-S510-P-017
TB-S510-P-018
TB-S510-P-019
Qty.
2 pcs
2 pcs
10 pcs
10 pcs
10 pcs
2 pcs
2 pcs
2 pcs
4 pcs
04
TOOLS NEEDED
PART LISTS
**PARTS MAY CHANGE WITHOUT FURTHER NOTICE.
13mm 10mm
5 x 15cm
PHILLIPS
6mm HEX KEY /
HEX SPANNER
