HGM410N/HGM420N GENSET
CONTROLLER USER MANUAL
4
HGM400N series controller has two types:
HGM410N: ASM (Automatic Start Module), it controls generator to start/stop by remote signal;
HGM420N: AMF (Auto Mains Failure), updates based on HGM410N, moreover, has mains electric quantity monitoring and mains/genera-
tor automatic transfer control function, especially for automatic system composed by generator and mains.
Items Contents
Working Voltage DC8. 0V to 35. 0V, Continuous Power Supply.
Overall Consumption <3W(Standby mode: ≤2W)
AC voltage Input:
3 Phase 4 Wire
3 Phase 3 Wire
Single phase 2 Wire
2 Phase 3 Wire
AC15V - AC360V (ph-N)
AC30V - AC620V (ph-ph)
AC15V - AC360V (ph-N)
AC15V - AC360V (ph-N)
Alternator Frequency 50Hz/60 Hz
Speed Sensor Voltage 1.0V to 24V (RMS)
Speed Sensor Frequency 10,000 Hz (max)
Start Relay Output 5A DC28V power supply
Auxiliary Relay Output 1 5A DC28V power supply
Auxiliary Relay Output 2 5A DC28V power supply
Auxiliary Relay Output 3 5A DC28V power supply
Auxiliary Relay Output 4 5A AC250V voltage-free output
Auxiliary Relay Output 5 5A AC250V voltage-free output
Overall Dimensions 126mm x 109mm x 44mm
Panel Cutout 110mm x 90mm
CT Secondary Current 5A (rated)
Working Condition Temperature: (-25~70)ºC;
Humidity: (20~90)%RH
Storage Condition Temperature: (-30~+80)ºC
Protection Level IP55 Gasket
Insulation Intensity Object: among input/output/power supply
Quoted standard: IEC688-1992
Test method: AC2.2kV/1min Ileak≤3mA
Weight 0.26kg
