Toyota 08691-00834 User Manual

Yaris (RHD) - 13
02-07
Yaris AUDIO
Fig. 10
17
13
1
17
13
15
1
17
10. Attach the spacers and the tapes
to the base bracket .
: Screw (M5x10) (4x)
: Spacer with nut (4x)
: Tape (2x)
1
17
15
13
1
17
11. Attach the base bracket to the floor
and fold back the cut parts of the carpet
.
14
3
Fig. 11
14
3
