4-3. Do-it-yourself maintenance
Engine compar
tment
2.4 L 4-cylinder (2AZ-FE) engine
Power steering
fluid
reservoir
(
→
P
. 328)
Engine oil filler cap
(
→
P
. 320)
Engine oil level dipstick
(
→
P
. 319)
Brake fluid reser
voir
(
→
P
. 327)
Fuse box
(
→
P
. 357)
Batter
y
(
→
P
. 330)
Radi
ator
(
→
P
. 326)
Electric cooling fans
Condenser
(
→
P
. 326)
W
asher f
luid t
ank
(
→
P
. 333)
Engine coolant reservoir
(
→
P
. 325)
337
339
