’01MY CELICA U (L/O 0008)
208
2001 CELICA (20766U)
Checking and replacing fuses
Good Blown
Type A
Good Blown
Type B
Good Blown
Type C
Good Blown
Type D
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” in Section 7–1 for
locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull a suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
Section 8 of this manual for the functions
controlled by each circuit.
Type A fuses can be pulled out by the
pull–out tool. The location of the pull–out
tool is shown in the illustration.
To Next Page
