Toyota Celica - Instrument Cluster Overview; Fuel Gauge

CEL11-0502ENUK-03-00
CEL11-0502ENUK-03-00
8
1. Tachometer
2. Service reminder indicators
and Indicator lights
3. Speedometer
4. Engine coolant temperature
gauge
5. Odometer and two trip
meters
6. Fuel gauge
7. Trip meter reset knob
Indicator symbols on the instrument panel
Instrument cluster overview
Brake system
warning light
Discharge
warning light
Low engine oil
pressure warning
light
Malfunction
indicator lamp
Low fuel level
warning light
Driver’s seat belt
reminder light
Front passenger
seat belt
reminder light
Anti-lock brake
system warning
light
SRS warning light
Open door
warning light
Turn signal
indicator lights
Tail light indicator
light
Headlight high
beam indicator
light
Rear fog light
indicator light
Front fog light
indicator light
Automatic
headlight leveling
system warning
light*
Vehicle stability
control system and
traction control
system warning
light*
Slip indicator light*
Traction control
system off
indicator light*
* on Celica T Sport only
