Jumper cable
Booster battery
Positive
terminal
(“+” mark )
Positive
terminal
(“+” mark )
Discharged
battery
4. Make t he cable c onnecti ons in the or-
der a, b, c, d.
a. Connect the c lamp of the pos iti ve
(red) jumper cable to the pos iti ve ( +)
termi nal on the dischar ged battery.
b. Connect the c lamp at the other end
of the posi tiv e (red) jumper cable t o
the positi ve (+) terminal on the booster
battery.
Jumper cable
Negative terminal
(“−”mark)
Booster
battery
Discharged
battery
c. Connec t the c lamp of the negative
(blac k) jumper cabl e to the negati ve ( −)
termi nal on the booster batt ery.
d. Connect the c lamp at the other end
of the negativ e (bl ack) jumper c able to
a solid, stat ionary, unpainted, metallic
point of the v ehicl e with t he disc harged
battery.
The recommended connect ing point i s
shown in the following illustration:
Connecting point
Do not c onnect the cable to or near
any part that mov es when t he engine
is cr anked.
CAUTION
When making the connecti ons, to
avoid death or seri ous i njury, do not
lean over the batt ery or accidental ly
let the jumper cables or clamps touch
anything except the cor rect batt ery
termi nals or the ground.
