Toyota Corolla 2016 - Engine Compartment

441
7-3. Do-it-yourself maintenance
7
Maintenance and care
COROLLA_TMMMS_TMMC_U (OM12J84U)
Engine compartment
Washer fluid tank (→P. 453)
Engine oil filler cap
(→P. 444)
Engine oil level dipstick
(→P. 442)
Brake fluid reservoir
(→P. 448)
Battery (→P. 450)
Fuse box (→P. 472)
Electric cooling fan
Engine coolant reservoir
(→P. 446)
Condenser (→P. 448)
Radiator (→P. 448)
1
2
3
4
5
6
7
8
9
10
