575
7
7-3. Do-it-yourself maintenance
Maintenance and care
1 When raising the wiper arms,
first lift up the driver side, and
then lift up the passenger side.
2 When returning the wiper arms
to their original positions, first
lower the passenger side, and
then lower the driver side.
■ Windshield wiper blade
removal and installation
1 Lift the wiper arm.
2 Lift the stopper using a flat-head
screwdriver as shown in the
illustration.
To prevent damage to the wiper arm,
protect the tip of the screwdriver with a
rag.
3 Slide the wiper blade to remove
it from the wiper arm.
When installing, reverse the steps
Wiper rubber replace-
ment
When replacing the wiper rub-
ber, perform the following pro-
cedure to operate each wiper.
Handling the front wiper
arms
Windshield wipers
To Next Page
