29
(1) Press “ ” switches and select from the Multi-Information Display (MID).
(2) Press “ ” switches and select from the MID.
(3) Press “
” from the meter switches.
Each time “ ” is pressed, the response to the warning distance changes as
follows:
Far
Middle (default)
Near
Note: The PCS warning timing is set when the power switch is turned off.
(1) Press “ ” switches and select from the Multi-Information Display (MID).
(2) Press “ ” switches and select from the MID.
(3) Press “
” from the meter switches.
The Pre-Collision System will be disabled.
Note: The system is automatically enabled each time the power switch is
turned to ON mode.
The Lane Departure Alert system recognizes visible white or yellow lane markers
via camera sensor. The system alerts the driver with a warning buzzer sound
and message in the Multi-Information Display (MID) when it detects the vehicle
deviating from or swaying multiple times within its lane.
Lane Departure Alert (LDA) with
Steering Assist (SA) function
Press the LDA switch to turn the LDA system on. Depress again to turn it off.
Note: The system will continue in the last state it was in (ON or OFF)
when the engine is started again.
Turning on the LDA system
Monocular camera sensor
Millimeter wave radar
As part of PC this function is also designed to rst provide an alert and then
automatic braking if needed.
Pedestrian Detection Function
The Pre-Collision System also features a pedestrian detection function. Using
a millimeter wave radar and monocular camera sensor, this advanced sensor
system can recognize pedestrians in some circumstances. It may provide detection
capability while driving at low as well as higher speeds.
SAFETY AND EMERGENCY FEATURESTOYOTA SAFETY SENSEFEATURES/OPERATIONSOVERVIEW
134261_Prius_QRG_GUTS.indd 29 12/18/15 1:32 PM
