Toyota Prius c 2012 - Engine Compartment

323
4-3. Do-it-yourself maintenance
4
Maintenance and care
PRIUS C_AE
Engine compartment
Fuse boxes (→P. 348)
Engine oil filler cap
(→P. 325)
Engine coolant radiator cap
Power control unit coolant
reservoir (→P. 328)
Engine coolant reservoir
(→P. 328)
Engine/power control unit
coolant radiator (→P. 330)
Electric cooling fan
Condenser (→P. 330)
Engine oil level dipstick
(→P. 324)
Washer fluid tank (→P. 330)
