TP active fun Single - Assembly Steps 5 & 6: Top Bar Attachment

12
Single, Double, Triple and Double with Extension
70mm FA8439
x2
MW0200 2700mm x2
M8 x25mm
FA8440
x2
5
5mm
5mm
70mm FA8439
x2
MW0200 2700mm x2
M8 x25mm
FA8440
x2
6
5mm
5mm
Generic view of Top Bar only.
Actual Top Bar will vary
depending on product purchased.
ASSEMBLY TIP
Single, Double, Triple and Double with Extension
