TP active fun Single - Assembly Steps 7 & 8: Beam and Bracket Fitting; Beam and Bracket Fitting; Equal Spacing of Brackets

TP active fun Single
16 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
13
Single, Double, Triple and Double with Extension
MW0189 900mm x2
70mm FA8439 x4
M8 x25mm
FA8440
x4
x2
Make sure that the fixing points
are centred on the legs.
ASSEMBLY TIP
7
Generic view of Top Bar only.
Actual Top Bar will vary
depending on product purchased.
ASSEMBLY TIP
5mm
4 x 16mm x2
FA4527
PM1968
x1
8
1
2
Equal
spacing
PM1007
x1
TP Generic Roundwood Swings In8047-E 19.05.20.indd 13TP Generic Roundwood Swings In8047-E 19.05.20.indd 13 19/05/2020 15:2619/05/2020 15:26
