TP-Link Deco X10 User Manual

2
Appearance
Each Deco has an LED that changes color according to its status, two RJ-45 Ethernet ports, a power slot, and a Reset button.
See the explanation below:
Tip: The product label can be found at the bottom of the product.
Pulse Yellow:
Deco is resetting.
Solid Yellow:
Deco is starting up.
Pulse Blue:
Deco is ready for setup.
Solid Blue:
Deco is setting up.
Pulse Green:
Deco is upgrading rmware.
Solid Green:
Deco is all set up and connected.
Pulse Red:
The satellite Deco is disconnected
from the main Deco.
Solid Red:
Deco has an issue.
Ethernet Ports:
For connecting Deco to your modem, the Ethernet outlet,
or for other internet services in Wireless Router mode.
Reset Button:
Press for 1 second and release to reset Deco to factory
default settings. The light changing from pulsing yellow to
solid yellow indicates a successful reset.
Power Slot:
For connecting Deco to the power socket via the provided
power adapter.

TP-Link Deco X10 Specifications

General

Antenna type	Internal
Product type	Mesh router
Reset button	Yes
Product color	White
Maximum coverage	190 m²
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Apps supported	TP-Link Deco
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Security algorithms	WPA, WPA2, WPA3
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
WLAN data transfer rate (max)	1500 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1201 Mbit/s
Operating modes	Router Mode, Access Point Mode
Number of guest networks (5 GHz)	1
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Width	110 mm
Height	114 mm
