LED Explanation
On: Power on.
O: Power o.
PWR
On: There is a valid link for FX Port.
Flashing: FX Port is transmitting or receiving data.
O: There is no valid link for FX Port.
Link/Act (for MC220L)
FX
On: There is a valid link for TP Port.
Flashing: TP Port is transmitting or receiving data.
O: There is no valid link for TP Port.
TP
Specications
For MC220L: IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z
For MC420L: IEEE 802.3, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3an, IEEE802.3z,
IEEE802.3ae, IEEE802.3x
PWR, FX Link/Act, TP Link/Act
For MC220L: SFP port, RJ-45 jack
For MC420L: SFP+ port, RJ-45 jack
For MC220L:
10Base-T: 2-pair UTP/STP of Cat. 3 or above (≤100m)
100Base-TX: 2-pair UTP/STP of Cat. 5 or above (≤100m)
1000Base-T: 4-pair UTP/STP of Cat. 5e or above (≤100m)
For MC420L:
1000BASE-T/2.5GBASE-T/5GBASE-T: 4-pair UTP/STP of Cat. 5e or above (≤100m)
10GBase-T: 4-pair UTP of Cat. 6 (≤55m), 4-pair UTP of Cat. 6a (≤100m)or 4-pair
STP of Cat. 6 or above (≤100m)
For MC220L: depends on the used SFP module
For MC420L: depends on the used SFP/SFP+ module
External Power Adapter: 9V/0.6A
Standards
LED
Twisted-Pair
Interface
General Specifications
Fiber &
Wave Length
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.
Do not point or stare directly into the beam or into the optical port of the transceiver when it is operating, as this can
injure your eyesight.
Use only power supplies which are provided by manufacturer and in the original packing of this product. If you have any
questions, please don't hesitate to contact us.
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the
Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
Operation Temperature 0˚C to 50˚C (32˚F to 122˚F)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Storage Humidity 5% to 90%RH non-condensing
Operation Humidity 10% to 90%RH non-condensing
Environmental and Physical Specifications
This is a class A product. In a domestic environment, this product may cause radio interference, in which case the user
may be required to take adequate measures.
CE Mark Warning
FCC STATEMENT
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів
та вимогам, що передбачені чинними законодавчими актами України.
CAN ICES-3 (A)/NMB-3(A)
Industry Canada Statement
xplana�on of the symbols on the product label
ymbols may vary from products. The label is at the bottom of the product.
Cla ss II equipment
Cla ss II equipment with functional earthing
Polarity of d.c. power connector
For indoor use only
Dangerous voltage
Caution, risk of electric shock
Energy eciency Marking
Protective earth
Earth
Frame or chassis
Functional earthing
Caution, hot surface
Caution
Operator's manual
Stand-by
"ON"/"OFF" (push-push)
Fuse
Fuse is used in neutral N
Caution, avoid listening at high volume l evels for l ong periods
Dis connection, all power plugs
m
Switch of mini-gap construction
µ
Switch of micro- gap construction (for US version)
Switch of micro-gap / micro
-
disconnection construction
(for other versions except US)
ε
Switch without contact gap (Semiconductor switching device)
RECYCLING
This product bears the selective sorting symbol for Waste
electrical and electronic equipment (WEEE). This means that
this product must be handled pursuant to European directive
2012/19/EU in order to be recycled or dismantled to minimize its
impact on the environment.
User has the choice to give his product to a competent recycling
organization or to the retailer when he buys a new electrical or
electronic equipment.
Responsible party:
TP-Link USA Corporation
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: sales.usa@tp-link.com
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Product Name: Omada Gigabit Ethernet Media Converter
Model Number: MC220L/MC420L
Power
Green On: FX Port is linked at 10Gbps, but there is no activity.
Green Flashing: FX Port is working at 10Gbps.
Yellow On: FX Port is linked at 1Gbps, but there is no activity.
Yellow Flashing: FX Port is working at 1Gbps.
O: There is no valid link for FX Port.
Link/Act (for MC420L)
FX
Green On: TP Port is linked at 10Gbps, but there is no activity.
Green Flashing: TP Port is working at 10Gbps.
Yellow On: TP Port is linked at 5Gbps/2.5Gbps/1Gbps, but
there is no activity.
Yellow Flashing: TP Port is working at 5Gbps/2.5Gbps/1Gbps.
O: There is no valid link for TP Port.
TP
Responsible party:
TP-Link USA Corporation
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: sales.usa@tp-link.com
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the
applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the
equipment is properly maintained and operated.
Issue Date: 2024.05.14
Product Name: Power Adapter
Model Number: T090060-2B1
Component Name Model
Power Adapter T090060-2B1
