TP-Link RE300 Quick Installation Guide

Q1. What should I do if I cannot access the extender’s web
management page?
Make sure your computer or smartphone has connected to the extender’s
network, and not that of your router. If your router and extender share the same
network name, use the Tether app.
If you are using a computer, make sure it is set to obtain an IP address and DNS
server address automatically.
Verify that http://tplinkrepeater.net or http://192.168.0.254 is correctly entered
in the web browser and press Enter. Note that http://192.168.0.254 applies only
for extenders with factory default settings.
Use another web browser and try again.
Reboot or reset the extender and try again.
If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi passwords for your host networks during
the conguration. Check the passwords and try again.
Make sure the extender is close to your router, preferably within 16 feet, and
away from large electrical appliances.
If you have enabled wireless MAC ltering, wireless access control, or access
control list (ACL) on your router, disable them rst, then follow any method on the
front page to complete the conguration.
Try setting up via the WPS button.
Reset the extender and go through the conguration again.
If you are still having problems, contact our technical support.
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button for 1 second.
The extender will reboot.
For technical support, the user guide and other information, please
visit https://www.tp-link.com/support, or simply scan the QR code.
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Do not use the device where wireless devices are not allowed.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Please read and follow the above safety information when operating the device. We cannot
guarantee that no accidents or damage will occur due to improper use of the device.
Please use this product with care and operate at your own risk.
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of directives 2014/53/EU, 2009/125/EC and 2011/65/EU. The original EU declaration of conformity may
be found at http://www.tp-link.com/en/ce.
TP-Link OneMesh router and extenders work together to form one unied Wi-Fi
network. Walk through your home and stay connected with the fastest possible
speeds thanks to OneMesh’s seamless coverage.
OneMesh
TM
with Seamless Roaming
Seamless Roaming
Devices automatically switch between your router and extenders as you move through your
home for the fastest possible speeds.
Unied Wi-Fi Network
Router and extenders share the same wireless settings, including network name, password,
access control settings and more.
Easy Setup and Management
Set up a OneMesh network with a push of WPS buttons. Manage all network devices on the
Tether app or at your router’s web management page.
Reset
To check full list of TP-Link OneMesh devices, scan the QR code,
or visit https://www.tp-link.com/One-Mesh/compatibility.
Method 2: Via a Web Browser
Method 1: Via the Tether App
1. Connect your computer or smartphone to the extender’s network . If you are
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://tplinkrepeater.net in the address bar, and
log in.
Note: If the login window does not appear, refer to FAQ > Q1.
3. Manage the extender as needed.
1. Connect your smartphone to the extender‘s or router’s network.
2. Launch the Tether app, select your extender, and log in.
3. Manage the extender as needed.
Manage the Extender
After setup, you can manage the extender via any of the methods below.
Note: If your extender and router use the same network name, Method 1 is recommended.
LED Explanation
LED Status Indication (For Range Extender Mode)
The extender is connected or not connected to the
5GHz wireless network of your host router.
5GHz On/O
The extender is connected or not connected to the
2.4GHz wireless network of your host router.
2.4GHz On/O
The extender is on or o.
The system is starting up or rmware is being upgraded.
(Power)
On/O
Blinking
The extender is connected to your router’s wireless
network and is in a suitable location.
The extender is experiencing poor signal strength. Try
relocating it closer to your router.
WPS connection is in progress.
No wireless connection is established.
(Signal)
Solid white
Solid red
Blinking
O
INTERNET
Unied OneMesh Network
SAME
Network Name & Password
for seamless roaming

TP-Link RE300 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows XP
Product color	White
Quantity per pack	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	7.3 W
Antenna type	Internal
Antennas quantity	2
Transmitting power (CE)	17 dBm
Package type	Box
Package depth	101.5 mm
Package width	156.5 mm
Package height	89 mm
Package weight	290 g
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	RoHS, Federal Communications Commission (FCC), CE

Weight and Dimensions

Depth	69 mm
Width	124 mm
Height	52 mm
