TP-Link RE355 User Manual

Introduction
Name
Status
Indication
RE
Blinking
WPS connection is in process.
Off
No active connection.
5GHz/
2.4GHz
On
The extender is connected to both 2.4GHz and
5GHz Wi-Fi bands of your host network.
Off
No connection.
Power
On
The extender is on.
Blinking
The extender is initializing.
Off
The extender is off.
 (Range Extender/WPS) Button: If your Wireless router supports WPS or
QSS function, you can press the WPS or QSS button and then press the RE
button to establish a secure connection between the Wireless router and the
extender.
 Reset Button: This button is used to restore the extender’s factory default
settings.
There are two ways to reset the extender:
Option One: With the extender powered on, use a pin to press the RESET
button until all the LEDs turn on momentarily, then release the button and
wait the extender to reboot to its factory default settings.
Option Two: Restore the default settings from System Tools > Backup
&Restore of the extender's Web-based Management page.
 LED Button:You can press the LED button to light up or turn off all the LEDs.
After the LEDs are off, the extender can still work normally.
 Power Button：You can press the Power button to turn on or off the extender.
 Ethernet Port: One 10/100Mbps RJ45 Ethernet port used to add wireless
connectivity to an Ethernet-enabled device such as Internet TV, DVR,
Gaming console and so on. Please note that this port is not allowed to be
connected with router.

TP-Link RE355 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
