TP-Link TL-R470T Quick Installation Guide

Router Conguration
4
Appendix: Troubleshooting
How do I restore my Router’s conguration to
its factory default settings?
1
2
Open web browser and type in http://192.168.0.1. Press
Enter button and then enter the User name and Password
(Factory Default: admin/admin), and click OK.
After a successful login, select the Quick Setup tab on
the left of the main menu and the “Quick Setup” screen
will appear. Then click Next.
Select the appropriate connection type according to the
information from your ISP. Then click Next.
Dynamic IP: If you choose Dynamic IP, the Router will
automatically obtain the IP parameters from
your ISP.
Static IP: If you choose Static IP, type in the IP address information
provided by your ISP. Then click Next.
Now you can see the following screen. Click Finish to complete
the quick installation.
TL-R470T+ provides three adjustable WAN/LAN ports which
can work as WAN port or LAN port. By the factory defaults,
TL-R470T+ is set to work in the dual-WAN ports mode with
port 1and port 2 as WAN ports, while port 3~5 are LAN ports.
The number of WAN/LAN ports can be set on the following
screen according to users’ requirements.
The Router will adjust the physical ports according to
specified number of WAN ports, which is illustrated by
the port sketch on the configuration screen. The yellow
color indicates that the port works as a WAN port while
green color indicates the LAN port.
With the Router powered on, use a pin to press and hold the
RESET button (about 5 seconds) until the SYS LED lights up
and flashes quickly. And then release the button and wait for
the Router rebooting to its factory default settings.
you can restore the Router to factory defaults. The default
management address of the Router is http://192.168.0.1, default
username and password are both admin. All your current settings
will be cleared after the Router is restored. If you have backup
configuration, please import it now.
Why does the PWR LED work abnormally?
The PWR LED should be lit up when the power system works
normally. If the PWR LED worked abnormally, please check
as follows:
1) Make sure that the power cable is connected properly,
and the power contact is normal.
2) Make sure the voltage of the power supply meets the
requirement of the input voltage of the Router.
Why does the page display abnormally?
Please check as follows:
1) Update your browser or replace it with another browser,
and try again.
2) If the pop-up is blocked, please lower the security level
of the browser.
What should I do if I could not access the
web-based conguration page?
You are recommended to check the following items:
1) Check every port LED on the Router and make sure the
cable is installed properly.
2) Try another port on the Router and make sure the cable
meets the requirement and works normally.
3) Turn off the power. After a while, turn on the power
again.
Make sure the IP address of your PC is set within the
subnet of the Router.
4)
If you still cannot access the configuration page, please
restore the Router to its factory defaults. Then the IP
address should be set as 192.168.0.x (“x” is any number
from 2 to 254) and Subnet Mask as 255.255.255.0.
5)
TP-LINK TECHNOLOGIES CO., LTD.
www.tp-link.com
Technical Support
www.tp-link.com/support/faq.asp
For more troubleshooting help, go to
www.tp-link.com/support/download.asp
To download the latest Firmware, Driver, Utility and User Guide, go to
For all other technical support, please contact us by using the
Tel: +44 (0) 845 147 0017
E-mail: support.uk@tp-link.com
Service time: 24 hrs, 7 days a week
UK
E-mail: support.sg@tp-link.com
Tel: +65 62840493
Singapore
Service time: 24 hrs, 7 days a week
Service time: 24 hrs, 7 days a week
E-mail: support@tp-link.com
Tel: +86 755 26504400
Global
Service time: 24 hrs, 7 days a week
E-mail:
support.usa@tp-link.com
Toll Free: +1 866 225 8139
USA/Canada
E-mail: support.de@tp-link.com
Fee: 0.14 EUR/min from the German
0.42 EUR/min from mobile phone.
Service Time: Monday to Friday
9:00 AM to 6:00 PM
GMT+1 or GMT+2
(Daylight Saving Time in Germany)
* Except bank holidays in Hesse
Tel: +49 1805 875465 (German
Service)/+49 1805 TPLINK
Germany/Austria
Service time: 24 hrs, 7 days a week
E-mail: support@tp-link.com.au
NZ 0800 87 5465
Tel: AU 1300 87 5465
Australia & New Zealand
Tel: +41 (0)848 800998
(German service)
E-mail: support.ch@tp-link.com
Fee: 4-8 Rp/min, depending on
Service time: Monday to Friday
9:00 AM to 6:00 PM.
GMT+1 or GMT+2
(Daylight Saving Time)
Switzerland
Tel: 444 19 25（Turkish Service）
E-mail: support.tr@tp-link.com
Service time: 9:00 AM to 6:00 PM,
7 days a week
Turkey
Tel: +39 02 66987799
E-mail: support.it@tp-link.com
Service time: 9:00 AM to 6:00 PM,
Monday to Friday
Italy
Tel: 1300 88 875465 (1300 88TPLINK)
E-mail: support.my@tp-link.com
Service time: 24 hrs a day,
7 days a week
Malaysia
Tel: (+62 ) 021 6259 135
E-mail: support.id@tp-link.com
Service time: Monday to Friday
9:00 -12:00 ; 13:00 -18:00
*Except public holidays
Indonesia
PPPoE: If you choose PPPoE, enter the User Name and
Password provided by your ISP. Then click Next.
Login
Connect to Internet
The Quick
Setup supports three connection types. For other
connection type, you can go to “Network”
3
WAN/LAN Conguration
following details.
What could I do if I forget the user name and
password of the Router?
What could I do if I forgot the username and
password of the Router?
In this part, the WAN port
you set is WAN1.
“WAN”.
TL-R470T+QIG_A1.pdf 2 2011-9-27 9:34:29

TP-Link TL-R470T Specifications

General

Protocols	TCP/IP, PPPoE, DHCP, ICMP, NAT
DHCP	DHCP Server, DHCP Client
Firewall Security	IP and MAC Address Binding
Ports	5 x RJ45 ports
VPN Support	PPTP VPN, L2TP VPN, IPSec VPN
Management	Web-based GUI
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
